- ModelPL-852D18M
- Image Sensor1/2.9” 1080p CMOS
- FOV55.4°(W) ~ 3.55°(T)
- Scanning SystemProgressive
- Eletronic ShutterAuto / Manual (1/5s – 1/100,000s)
- Min. illumination0.05Lux (color), 0.01Lux (BW), 0 Lux with IR on
- IR Range7pcs Array LED + 3pcs Laser IR + 2pcs Warm Stroble Lights, 150m
- CompressionH.265 / H.264
- ResolutionMain Stream: 1080p@25f/s
Sub Stream: 640 * 480@25f/s - Bit RateMain Stream: 1024Kbps ~ 4Mbps
Sub Stream: 160Kbps ~ 896Kbps - Bit Rate ControlCBR / VBR
- Audio CompressionG.711a / G.711u (32Kbps) / PCM (128Kbps)
- BLCSupported
- Human DetetionLinkage with Sound / Strobe light and Track by human detection alarm
- Audio I/OBuilt-in with Speaker and Microphone
- WDRDWDR
- Day / NightAuto(ICR) / Color / B / W
- White BalanceAuto / Custom / Locked WB / Incandescent Lamp / Warm Light / Natural Light / Fluorescent Lamp
- Gain ControlAuto
- Noise Reduction2D & 3D DNR
- Privacy MaskUp to 5 areas
- Network
- ProtocolTCP/IP, UDP, HTTP, DHCP, RTSP, NTP
- OnvifOnvif profile S
- Max. Online Users3
- Web BrowserIE, Chrome, Firefox
- P/T
- Pan / Tilt RangePan: 0°~ 360°, Tilt: -5°~ 90°
- Pan Speed0 ~ 180°/s
- Tilt Speed0 ~ 100°/s
- Preset255
- Preset Speed7-Level selection
- Pattern Group4
- Auto ModeSupport Idle motion, Power-on auto detection, Rotation speed changes with optical zoom proportionally
- ProtocolPelco-D, Pelco-P
- Net Weight3.5kg
- Ingress ProtectionIP66
- Working Environment-20°C ~ 60°C, RH＜90%
- Power SupplyPoE / DC 12V 4A
- Lightning ProtectionEDS 4000V
- Tour Group8
- A-B Scan Group8
- Dimensions (L*W*H)Φ185 * 375 (mm)
- Gross Weight4.5kg
- Ordering Information
- Type2MP PTZ Camera
- Part NumberPL-852D18M
- Description6 inches 2MP PTZ camera, 18X
PL-852D18M | IP PTZ Camera
In Stock
Highlights:
Compare
System Overview
PL-852D18M is featured by the mini compact design which is only 6 inches and easy for installation.
Powered by the cutting edge human detection technology, it could guard your region safely and filter out the false alarm.
Coming with default PoE function, it brings more convenience to the installer for cabling and saving the labor cost.
With pan speed up to 180°/s, and tilt speed up to 100°/s, it would promise a large HD video coverage and secured details.
It’s the ideal choice for SMB solutions, such as buildings, factories, schools which are designed for indoor and outdoor.
Functions H.265 Delivering high quality video with up to 70% lower bandwidth. H.265 is the optimized evolution of traditional H.264.
H.265 technology includes a series of encoding strategy like Dyamic ROI, smart 2D&3D noise reduction etc to save up to 70% bandwidth and storage.
Harsh conditions ZKTeco PTZ cameras could run normally in harsh environment, working temperature range from -20°C~60°C with 90% humidity.
